Model |
NTP 1100 |
NTP 900AF (Air Flushing) |
Voltage (V/HZ) |
220/50 |
220/50 |
Power (W) |
230 |
835 |
Heat Sealing Power (W) |
300x4 |
40x2 |
Sealing Speed (m/min) |
0 ~ 10 |
0-12 (0-16) |
Sealing Width (mm) |
8 ~ 10 |
8 ~ 10 |
Temperature Range (°C) |
0 ~ 300 |
0 ~ 300 |
Distance from the Sealing Center to the Conveying Table (mm) |
Nil |
10 ~ 40 |
Conveyor Size (L x W) mm |
1400x250 |
930x180 |
Film Thickness (mm) |
0.12 to 0.18 |
0.08 |
Single Conveyor Loading (Kg) |
5 |
1 |
Overall Conveyor Loading (Kg) |
15 |
3 |
Overall Dimension (L x W x H) mm |
1450 x 680 x 1480 |
1050 x 560 x 900 |
Net Weight (Kg) |
107 |
62 |
